Radial Layer
Last updated 10.01.2024
A layer that provides a gradient that rotates around a single point and optionally spins.
Note that this gradient is generated using discrete pie-shaped segments of colour. This color is determined by the median color at a particular point on the gradient. For example, if there were 4 segments, each would have a 90 degree arc. The first would use the color at 45 degrees (90 / 2) the second at 135 degrees, etc. If you do not get the colors you expect when using small numbers of segments, this is likely the reason.
Properties
Name | Description |
---|---|
Gradient | The gradient of the layer. |
Rotation speed | The rotation speed of the layer, in degrees per second. Positive will spin clockwise, negative for counter-clockwise. |
Segment count | The number of segments (see above) that are used to create the gradient. A lower number will result in distinct blocks of colour whereas a higher number will result in a smoother transition. |
Affected keys | The keys or region to apply the gradient to. |
